2024
Fat Boy™ 114
Knockout punch from the heavyweight division.
Starting Price ฿1,250,000
COLOR OPTIONS
2024 Fat Boy™ 114
The original fat custom icon. Loved since day one, the Harley-Davidson® Fat Boy 114 stands out with bright chrome and bold finishes.
KEY FEATURES

Milwaukee-Eight® 114 Engine
Full-throttle torque for the power you want, which you can feel every time you twist the throttle, along with the most exciting HD sound.

High performance front suspension
Advanced suspension technology provides lighter weight with reduced friction properties.

Bright chrome
If the size of the car doesn't appeal to you, then the bright chrome color is the one.
DETAILED SPECS
Dimensions
Length | 2,370 mm.
|
Seat Height, Laden | 675 mm.
|
Height from ground | 115 mm.
|
Front fork offset | 34
|
Rear range | 104 mm.
|
Wheelbase | 1,695 mm. |
Types of tires | Michelin ™ Scorcher "11" front and rear tires
|
Front tire specifications | 160/60R18,70V,BW |
Rear tire specifications | 240/40R18,79V,BW |
Fuel capacity | 18.9 liters |
Engine oil capacity (with filter) | 4.7 liters
|
Shipping weight | 304 kg. |
Ready to ride weight | 317 kg. |
Engine
Engine | Milwaukee-Eight ™ 114 |
Cylinder size | 102 mm. |
Stroke duration | 114.3 mm. |
Engine capacity | 1,868 cc |
Compression ratio | 10.5:1 |
Fuel system | Sequential Electronic Fuel Injection (ESPFI) |
Exhaust | 2-in-2 stacked cathode pipe |
Capacity
How to test engine torque | EC 134/2014 |
Engine torque | 155 Nm |
Engine torque (rpm) | 3250 |
Horsepower | 94 hp / 70 kW at 5020 rpm |
Right turning angle (degrees) | 25.6 |
Left turning angle (degrees) | 25.6 |
How to test fuel economy | EU 134/2014 |
Fuel economy | 5.5 liters/100 km. |
Drive System
Main propulsion system
| Chain gear ratio 34/46 |
Gear Ratios (overall) 1st | 9.311 |
Gear Ratios (overall) 2nd | 6.454
|
Gear Ratios (overall) 3rd | 4.793
|
Gear Ratios (overall) 4th | 3.882
|
Gear Ratios (overall) 5th | 3.307
|
Gear Ratios (overall) 6th | 2.79
|
Chassis
Front shock
| 49mm Dual Bending valved telescopic fork with triple clamp aluminum shock column; Integrated dual-value spring; "beer can" cap |
Rear shock | Independent hidden piston, single shock with spring, 43 mm stroke and hydraulic preload adjustment without tools. |
Type of front wheel | Polished Lakester Aluminum |
Type of rear wheel | Polished Lakester Aluminum |
Types of brake calipers | 4 front pistons fixed and 2 rear pistons floating |
Brake disc type | 7-spoke black floating front and rear brake discs |
Electric
Lights (as per country regulation), indicator
| All LED headlights, low and high beams with unique positioning lights, LED multi-function stop/tail/turn signals, Bullet incandescent turn signals, LED multi-function stop/tail/turn signals |
Gauges
| 5-inch analog speedometer with digital gear, odometer, fuel level, clock, trip, range and tachometer. |
Color Options
Billiard Grey
| ฿1,250,000 |
Vivid Black | ฿1,255,000 |
Red Rock | ฿1,256,000 |
Sharkskin Blue | ฿1,257,000 |
